Instrument case
585 mm W x 535 mm D x 410 mm H
(total height with coating head open: 650 mm)
Weight
28 kg (packed: 42 kg)
Packed dimensions
725 mm W x 660 mm D x 680 mm H
Work chamber
Borosilicate glass 150 mm ID x 127 mm H
Display
115.5mm W x 86.4mm H (active area), 640 RGB x 480 (display format), capacitive touch colour display
User interface
Full graphical interface with touch screen buttons includes features such as a log of the last 1000 coatings and reminders for when maintenance is due.
Carbon evaporation source
Carbon fibre woven cord 1m is supplied with carbon fibre head as standard. Carbon rod head option available. R E and R ES versions only.
Specimen stage
50 mm Ø rotation stage with rotation speed of 8-20 rpm.
Other stages available on request.
